Pixelink相机

　　Pixelink USB 3.0相机
分辨率高达14MP
传感器尺寸从?"到1.1"
有直角外壳版本和裸板结构版本可以获得
Pixelink?USB 3.0相机是高分辨率且高速的解决方案，适用于从生物识别到监控的各种应用。Pixelink?USB 3.0相机具有高达14MP的分辨率、高达150fps的帧率以及适用于各种功率和高数据吞吐量的USB 3.0兼容性。直角外壳配置还具有GPIO，可启用触发以便于系统集成。这些USB 3.0相机还能与尺寸从?"到1.1"的传感器兼容，并且非常适合检查焊接和PCB以及平板显示器。
Pixelink USB 3.0相机通用规格
相机系列:PL-D
生产商:Pixelink?
曝光控制触发器:Freely Programmable
支架:C-Mount
操作系统:Software Driver:Windows 32 and 64 bit
功率要求:Via USB 3.0 interface
工作温度(°C):0 to+50
传感器类型:Progressive Scan CMOS
视频输出:USB 3.0
订购信息：
型号摄像机传感器格式分辨率像素(HxV)类型产品编码
(MegaPixels)
PL-D721MU-T 1/2"1.3 1,280 x 1,024 Monochrome Camera#89-378
PL-D721CU-T 1/2"1.3 1,280 x 1,024 Color Camera#89-379
PL-D721MU-BL 1/2"1.3 1,280 x 1,024 Monochrome Camera#89-380
PL-D721CU-BL 1/2"1.3 1,280 x 1,024 Color Camera#89-381
PL-D722MU-T 2/3"2.3 1,920 x 1,200 Monochrome Camera#89-382
PL-D722CU-T 2/3"2.3 1,920 x 1,200 Color Camera#89-383
PL-D722CU-T 2/3"2.3 1,920 x 1,200 Color Camera#89-383-RCD-05P
PL-D722MU-BL 2/3"2.3 1,920 x 1,200 Monochrome Camera#89-384
PL-D722CU-BL 2/3"2.3 1,920 x 1,200 Color Camera#89-385
PL-D775MU-T 1/2.5"5 2,592 x 1,944 Monochrome Camera#89-386
PL-D775CU-T 1/2.5"5 2,592 x 1,944 Color Camera#89-387
PL-D725MU-T 1"5.3 2,592 x 2,048 Monochrome Camera#89-390
PL-D775MU-BL 1/2.5"5 2,592 x 1,944 Monochrome Camera#89-388
PL-D775CU-BL 1/2.5"5 2,592 x 1,944 Color Camera#89-389
PL-D725CU-T 1"5.3 2,592 x 2,048 Color Camera#89-391
PL-D729MU 2/3"9.6 3,840 x 2,500 Monochrome Camera#89-394
PL-D729MU 2/3"9.6 3,840 x 2,500 Monochrome Camera#89-394-RCD-05P
PL-D725MU-BL 1"5.3 2,592 x 2,048 Monochrome Camera#89-392
PL-D725CU-BL 1"5.3 2,592 x 2,048 Color Camera#89-393
PL-D725CU-BL 1"5.3 2,592 x 2,048 Color Camera#89-393-RCD-05P
PL-D729MU 2/3"9.6 3,840 x 2,500 Monochrome Camera#89-396
PL-D7715CU 1/2.3"15 4,608 x 3,288 Color Camera#89-398
PL-D7715CU-BL 1/2.3"15 4,608 x 3,288 Color Camera#89-400
PL-D726MU-BL 1"6.6 2,208 x 3,000 Monochrome Camera#89-402
PL-D732MU-T 2/3"2.2 2,048 x 1,088 Monochrome Camera#33-338
PL-D732CU-T 2/3"2.2 2,048 x 1,088 Color Camera#33-339
PL-D732MU-BL 2/3"2.2 2,048 x 1,088 Monochrome Camera#33-340
PL-D732CU-BL 2/3"2.2 2,048 x 1,088 Color Camera#33-341
PL-D734MU-T 1"4.2 2,048 x 2,048 Monochrome Camera#33-342
PL-D734CU-T 1"4.2 2,048 x 2,048 Color Camera#33-343
PL-D734MU-BL 1"4.2 2,048 x 2,048 Monochrome Camera#33-344
PL-D734CU-BL 1"4.2 2,048 x 2,048 Color Camera#33-345
PL-D752MU-T 1/1.2"2.3 1,920 x 1,200 Monochrome Camera#33-346
PL-D752CU-T 1/1.2"2.3 1,920 x 1,200 Color Camera#33-347
PL-D752MU-BL 1/1.2"2.3 1,920 x 1,200 Monochrome Camera#33-348
PL-D752CU-BL 1/1.2"2.3 1,920 x 1,200 Color Camera#33-349
PL-D795 2/3"5.01 2,448 x 2,048 Monochrome Camera#38-005
PL-D795 2/3"5.01 2,448 x 2,048 Color Camera#38-006
PL-D795 2/3"5.01 2,448 x 2,048 Color Camera#38-006-RCD-05P
PL-D799 1"9 4,096 x 2,160 Monochrome Camera#38-007
PL-D799 1"9 4,096 x 2,160 Color Camera#38-008
PL-D7912 1.1"12 4,096 x 3,000 Monochrome Camera#38-009
PL-D7912 1.1"12 4,096 x 3,000 Color Camera#38-010
PL-D755MU-T 2/3"5.01 2,448 x 2,048 Monochrome Camera#11-436
PL-D755CU-T 2/3"5.01 2,448 x 2,048 Color Camera#11-437
PL-D755MU-BL 2/3"5.01 2,448 x 2,048 Monochrome Camera#11-438
PL-D755CU-BL 2/3"5.01 2,448 x 2,048 Color Camera#11-439
PL-D759MU-T 1"8.85 4,096 x 2,160 Monochrome Camera#11-440
PL-D759CU-T 1"8.85 4,096 x 2,160 Color Camera#11-441
PL-D759MU-BL 1"8.85 4,096 x 2,160 Monochrome Camera#11-442
PL-D759CU-BL 1"8.85 4,096 x 2,160 Color Camera#11-443
PL-D7512MU-T 1.1"12.29 4,096 x 3,000 Monochrome Camera#11-444
PL-D7512CU-T 1.1"12.29 4,096 x 3,000 Color Camera#11-445
PL-D7512MU-BL 1.1"12.29 4,096 x 3,000 Monochrome Camera#11-446
PL-D7512CU-BL 1.1"12.29 4,096 x 3,000 Color Camera#11-447
技术数据
技术信息
Software Specifications
Pixelink?API Control
Line Profiling:Single,Multiple,Parallel and Polyline Commands Provide Gray/Red/Green/Blue Intensity Values for Specific Lines within an Image.The Profile Data of Each Pixel on the Line Can Be Exported to Microsoft?Excel?.
Multiple Image File Formats:jpg,jpeg,tif,tiff,bmp,gif,pcx,tga,mpg,mpeg,avi,mov,img,rpt,txt
Overlay:Crosshair,Grid Mask,Image,Marker
Image:Mode Change,Clone,Crop,ROI,Resize,Rotate
Zoom Control:100-1600%and Fit to Window Options
Annotation:Line,Arrow,Polyline,Spline,Rectangle,Ellipse,Text
Image Sequence Control
Image Editing:Undo,Redo,Copy,Paste,Paste New,Delete,Delete All,Annotate,Image Information
Multiple Window Configurations
Export to Excel?:Images with Measurement,Calibration,Annotations,Measurement Data,Statistics,and Chart
Measurement Parameters:Area,Max Length,Line Length,Center x and y,Angle
Live Measurement and Overlay:Perform Measurements on the Live Preview Image,Using the Crosshair or Grid Masks to Center and Count.The Grid Masks include Calibration Data.
Dynamic User Interface
Manual Calibration
Report Generator:Create,Insert Images and OLE Objects
Manual Measurement Tools:3-Point Circle Functionality,npoint Circle Measurement Functionality,Parallel Line Distance Measurement,Perpendicular Distance Measurement and Object Distance Measurement,Zoom-In Window
Time Lapse Capture and Movie File Production with Crosshair on Live Preview
Calibration Marker(Scale Bar)Can Be Placed on the Live Preview Image and Burned in Automatically
Multiple ROI:Shapes and Copy,Paste,Crop ROI
Image Processing:manual brightness,contrast,gamma,background subtraction,histogram,clone,crop,ROI,resize,rotate,split,image mode change,grayscale,RGB,HSB,YUV pseudo color view
Auto and Semi-Auto Calibration
Profile:Straight line,Polyline,Parallel Line,Select and Change
Image Stitching
Z-axis Extended Focus Imaging with Displacement Compensation
3D Visualization to Clearly View Complex Structures
Auto Trace Using Automatic Edge Detection
Fluorescent Image Composition
Fast and Perfect Focus Enhancement
Shading Correction
Reflected Light Subtraction
