浙江双庆阀门厂家直销SQCSSH双联切换过滤器

双联切换过滤器

浙江双庆阀门双联切换过滤器是一种由两台不锈钢过滤器并联而成，具有结构新颖合理、密封性好、流通能力强、操作简便等诸多优点，应用范围广泛、适应性强的多用途过滤设备。

Zhejiang Shuangqing Valve Dual Switching Filter is a kind of multi-purpose filter equipment, which is composed of two stainless steel filters in parallel. It has many advantages, such as novel and reasonable structure, good sealing, strong circulation ability, simple operation and so on. It has a wide range of applications and strong adaptability.

双联切换过滤器

尤其是滤袋侧漏机率小，能准确地保证过滤精度，并能快捷地更换滤袋，过滤基本无物料消耗，使得操作成本降低。

Especially the filter bag side leakage rate is small, can accurately guarantee the filtering accuracy, and can quickly replace the filter bag, filtering basically no material consumption, making the operation cost reduced.

双联切换过滤器结构特点

双联切换式过滤器又称并联切换过滤器，采用两个三通球阀，将两个单筒过滤器组装在一个机座上，清洗过滤器时不必停车，保证其连续工作，是不停车生产线过滤装置，本过滤器的过滤元件，除采用不锈钢滤芯外，亦可采有优质蜂房式脱脂纤维棉，可滤掉粒径1μ以上的颗粒，本过滤器亦可单筒使用，此时只需去掉共同机座，其余尺寸不变。

双联过滤器内外表面抛光处理，滤筒内装有不锈钢滤网和滤网支撑篮；顶部装有放气阀，供过滤时排放滤器内空气作用。上盖与滤筒连接采用快开式结构，更方便清洗(更换)滤网，三只可调节式支脚可使滤器平稳放置在地面上。连接管路采用活接或卡箍连接方式，进出料阀门采用三通球阀启闭，耐压耐温，操作灵活方便，无料液泄漏更卫生。

Dual switching filter, also known as parallel switching filter, uses two three-way ball valves to assemble two single-barrel filters on a machine seat. When cleaning the filter, it does not need to stop to ensure its continuous operation. It is the preferred filter device for non-stop production line. The filter element of this filter, besides stainless steel filter element, can also be used. High quality honeycomb degreased fibre cotton can be used to filter particles with a diameter of more than 1 mu. The filter can also be used in a single drum. At this time, only the common machine seat is removed, and the other sizes remain unchanged.

双联过滤器内外表面抛光处理，滤筒内装有不锈钢滤网和滤网支撑篮；顶部装有放气阀，供过滤时排放滤器内空气作用。上盖与滤筒连接采用快开式结构，更方便清洗(更换)滤网，三只可调节式支脚可使滤器平稳放置在地面上。连接管路采用活接或卡箍连接方式，进出料阀门采用三通球阀启闭，耐压耐温，操作灵活方便，无料液泄漏更卫生。

The inner and outer surfaces of the double filter are polished, and stainless steel mesh and mesh support basket are installed in the filter cartridge. The top of the filter is equipped with an air vent valve for discharging air in the filter when filtering. The top cover and the filter barrel are connected by a fast-opening structure, which makes it easier to clean (replace) the filter screen. Three adjustable legs enable the filter to be placed on the ground smoothly. Connecting pipes adopt flexible connection or clamp connection mode. Input and outlet valves adopt three-way ball valve to open and close. It is pressure-resistant and temperature-resistant, flexible and convenient to operate, and leak-free liquid is more hygienic.

双联切换过滤器适用范围

1、化工，石油化工生产中的弱腐蚀性物料，如：水、氨、油品、烃类等。

2、化工生产中的腐蚀性物料，如：烧碱、浓稀硫酸、碳酸、醋酸等。

3、制冷中的低温物料，如：液甲烷、液氨、液氧和各种冷剂。

4、轻工食品，制药生产中有卫生要求的物料，如：啤酒、饮料、乳制品、粮浆医药用品等。

1. Chemical industry, weak corrosive materials in petrochemical production, such as water, ammonia, oil, hydrocarbons, etc.

2、化工生产中的腐蚀性物料，如：烧碱、浓稀硫酸、碳酸、醋酸等。

2. Corrosive materials in chemical production, such as caustic soda, concentrated sulfuric acid, carbonate, acetic acid, etc.

3、制冷中的低温物料，如：液甲烷、液氨、液氧和各种冷剂。

3. Low temperature materials in refrigeration, such as liquid methane, liquid ammonia, liquid oxygen and various refrigerants.

4、轻工食品，制药生产中有卫生要求的物料，如：啤酒、饮料、乳制品、粮浆医药用品等。

4. Light industrial food and materials with hygienic requirements in pharmaceutical production, such as beer, beverage, dairy products, grain pulp and medical supplies.

双联切换过滤器尺寸及技术参数

1. 过滤面积：0.15㎡、0.30㎡、

2. 过滤能力：5t/h、10t/h；

3. 适用温度：≤120℃；

4. 滤网孔径：60～400目(供选)；

5. 工作压力：≤0.2MPa；

6. 滤器材质：304/316L；

7. 进出口管径：32mm、40mm；

8. 内外表面处理方式：内镜面抛光，外镜面抛光或亚光。

1. Filtration area: 0.15, 0.30,

2. 过滤能力：5t/h、10t/h；

2. Filtration capacity: 5t/h, 10t/h;

3. 适用温度：≤120℃；

3. Applicable temperature: <120 C;

4. 滤网孔径：60～400目(供选)；

4. Screen aperture: 60-400 meshes (for selection);

5. 工作压力：≤0.2MPa；

5. Work pressure: <0.2 MPa;

6. 滤器材质：304/316L；

6. Filter material: 304/316L;

7. 进出口管径：32mm、40mm；

7. import and export pipe diameters: 32mm, 40mm;

8. 内外表面处理方式：内镜面抛光，外镜面抛光或亚光。

8. Internal and external surface treatment: endoscopic polishing, external mirror polishing or matte.

五、应用领域

1.生活供水、生产工艺给水过滤。

2.超滤、反渗透、软化、离子交换等预处理。

3.海珍品育苗用海水净化；工厂化海水及淡水养殖用水过滤。

4.油田回注水过滤。

5.循环冷却水过滤。

6.中水回用、废水深度处理过滤。

7.钢铁、石油、化工、造纸、汽车、食品、冶金等行业循环水过滤。

8.地下水、地表水除浊净化。

9.中央空调、锅炉回水过滤。

10.对水质有一定要求的设备给水过滤。

11.泳池、景观水质净化。

12.市政、绿地喷洒、浇灌，农业喷灌、滴灌用水过滤。

1. Domestic water supply and production process water filtration.

2.超滤、反渗透、软化、离子交换等预处理。

2. Ultrafiltration, reverse osmosis, softening, ion exchange and other pretreatments.

3.海珍品育苗用海水净化；工厂化海水及淡水养殖用水过滤。

3. Seawater purification for nursery of marine treasures; filtration for industrial seawater and freshwater aquaculture water.

4.油田回注水过滤。

4. Filtration of oilfield reinjection water.

5.循环冷却水过滤。

5. Circulating cooling water filtration.

6.中水回用、废水深度处理过滤。

6. Reclaimed water reuse, advanced treatment and filtration of wastewater.

7.钢铁、石油、化工、造纸、汽车、食品、冶金等行业循环水过滤。

7. Circulating water filtration in steel, petroleum, chemical, paper, automobile, food and metallurgy industries.

8.地下水、地表水除浊净化。

8. Deturbidization and purification of groundwater and surface water.

9.中央空调、锅炉回水过滤。

9. Central air conditioning and boiler backwater filtration.

10.对水质有一定要求的设备给水过滤。

10. Equipment feedwater filtration with certain requirements for water quality.

11.泳池、景观水质净化。

11. Water purification of swimming pool and landscape.
