NSK气钻SPINDLE

产品简介

 NSK气钻广泛应用于CCD/X-RAY钻靶机及金手指斜边机,本公司为NSK的一级代理商，低价销售、维修NSK全系列气钻，保证价格低、品种全、交货快。
NSK气钻SPINDLE
编号 气钻名称 外径 转速 功率
1021 AM-300R 22.8mm 30,000min-1(rpm) 57W
1083 AM-300L 22.8mm 30,000min-1(rpm) 57W
1018 AM-300RA 22.8mm 30,000min-1(rpm) 57W
1084 AM-300LA 22.8mm 30,000min-2(rpm) 57W
1079 AM-310R 22.8mm 30,000min-2(rpm) 108W
1085 AM-310L 22.8mm 30,000min-2(rpm) 108W
1081 AM-310RA 22.8mm 30,000min-2(rpm) 108W
1082 AM-310LA 22.8mm 30,000min-2(rpm) 108W
1071 AM-600R 22.8mm 58,000min-1(rpm) 76W
2512 AM-600RA 22.8mm 55,000min-1(rpm) 69W
8220 NR-2351 22.8mm 30,000min-1(rpm)
1020 NR-301 22.8mm 30,000min-1(rpm)
1020 NR-2301 22.8mm 30,000min-1(rpm)
2511 NR-310 22.8mm 30,000min-1(rpm)
1073 NR-601 22.8mm 60,000min-1(rpm)
1801 AM-2526R 25mm 24,000min-1(rpm) 130W
1802 AM-2526L 25mm 24,000min-1(rpm) 130W
1803 AM-2526RA 25mm 22,000min-1(rpm) 120W
1804 AM-2526LA 25mm 22,000min-1(rpm) 120W
 8333 EM25-5000-J4 25mm 50,000min-1(rpm) 125W
1819 NR-2551 25mm 50,000min-1(rpm)
1809 NR-2532 25mm 30,000min-1(rpm)
1797 AM-3020R 30mm 19,000min-1(rpm) 130W
1798 AM-3020L 30mm 19,000min-1(rpm) 130W
1799 AM-3020RA 30mm 18,000min-1(rpm) 125W
1800 AM-3020LA 30mm 18,000min-1(rpm) 125W
9027 EM-405 30mm 40,000min-1(rpm) 270W
1565 NR-402E 30mm 40,000min-1(rpm)
1565 NR-403E 30mm 40,000min-1(rpm)
1566 NR-453E 30mm 50,000min-1(rpm)
1534 AMS-20R 53mm 2,200min-1(rpm) 131W
1528 AMS-50R 53mm 4,000min-1(rpm) 131W
1529 AMS-150R 53mm 15,000min-1(rpm) 132W
1530 AMS-250 47mm 25,000min-1(rpm) 105W



AM-300R/L、AM-310R/L、AM-600R、NR-2301、NR-2351



 产品简介


NSK 气钻 SPINDLE
气钻图片 编 号 型  号 外径 转 速 功 率
  1021 AM-300R 22.8mm 30,000min-1(rpm) 57W
  1083 AM-300L 22.8mm 30,000min-1(rpm) 57W
  1018 AM-300RA 22.8mm 30,000min-1(rpm) 57W
  1084 AM-300RL 22.8mm 30,000min-1(rpm) 57W
  1079 AM-310R 22.8mm 30,000min-1(rpm) 108W
  1085 AM-310L 22.8mm 30,000min-1(rpm) 108W
  1081 AM-310RA 22.8mm 30,000min-1(rpm) 108W
  1082 AM-310LA 22.8mm 30,000min-1(rpm) 108W
  1071 AM-600R 22.8mm 58,000min-1(rpm) 76W
  2512 AM-600RA 22.8mm 55,000min-1(rpm) 69W
  1020 NR-2301 22.8mm 30,000min-1(rpm)
  8220 NR-2351 22.8mm 30,000min-1(rpm)
  2511 NR-310 22.8mm 30,000min-1(rpm)
  1074 AMH-301 22.8mm 30,000min-1(rpm)
  1073 NR-601 22.8mm 60,000min-1(rpm)


AM-3020R/L、AM-3020RA、AM-3020LA



 产品简介


NSK 气钻 SPINDLE
气钻图片 编 号 型  号 外径 转 速 功 率
  1797 AM-3020R 30mm 19,000min-1(rpm) 130W
  1798 AM-3020L 30mm 19,000min-1(rpm) 130W
  1799 AM-3020RA 30mm 18,000min-1(rpm) 125W
  1800 AM-3020LA 30mm 18,000min-1(rpm) 125W


EM-401、EM-405、EM-505



 产品简介


NSK气钻SPINDLE
气钻图片 编 号 型  号 转 速 功 率
  1503 EM-401 40,000min-1
  9027 EM-405 40,000min-1
  9069 EM-505 50,000min-1


NR-402E、NR-403E、NR-453E



 产品简介


NSK 气钻 SPINDLE
气钻图片 编 号 型  号 外径 转 速 功 率
  1565 NR-402E 30mm 40,000min-1(rpm)
  1565 NR-403E 30mm 40,000min-1(rpm)
  1566 NR-453E 30mm 50,000min-1(rpm)


AM-2526R/L、NR-2532、NR-2551



 产品简介


NSK 气钻 SPINDLE
气钻图片 编 号 型  号 外径 转 速 功 率
  1081 AM-2526R
AM-2525R 25mm 24,000min-1(rpm) 130W
  1082 AM-2526L
AM-2525L 25mm 24,000min-1(rpm) 130W
  1083 AM-2526RA 25mm 22,000min-1(rpm) 120W
  1084 AM-2526LA 25mm 22,000min-1(rpm) 120W
  1819 NR-2550
NR-2551 25mm 50,000min-1(rpm)
  1909 NR-2531
NR-2532 25mm 50,000min-1(rpm)

AMS-250、AMS-20R、AMS-50R、AMS-150R



 产品简介


NSK 气钻 SPINDLE
气钻图片 编 号 型  号 外径 转 速 功 率
  1534 AMS-20R 53mm 2,200min-1(rpm) 131W
  1528 AMS-50R 53mm 4,000min-1(rpm) 131W
  1529 AMS-150R 53mm 15,000min-1(rpm) 132W
  1530 AMS-250 47mm 25,000min-1(rpm) 105W
  1531 AMS-600 64mm 60,000min-1(rpm) 34W
  1093 AMS-1200 22.8mm 120,000min-1(rpm) 34W
  1533 AMS-1501 44.5mm 150,000min-1(rpm) 21W

NSK气钻控制器 NE145、NE147、NE72、NE123、NE211



 产品简介


产品图片 名称 电源 频率 功率 尺寸
  NE72 AC110V 50/60Hz 75W W225 x D195 x H97mm
  NE123 AC200-240V 50/60Hz 150W W430 x D487 x H177mm
  NE145 AC100-240V 50/60Hz 92W W108xD156xH175mm
  NE147 AC100-240V 50/60Hz 180W W210×D290×H97mm
  NE211 AC100-240V 50/60Hz 350W W88×D138×H238mm
