Pixelink相机介绍

　　Pixelink USB 3.0相机

　　分辨率高达14MP

　　传感器尺寸从?"到1.1"

　　有直角外壳版本和裸板结构版本可以获得

　　Pixelink?USB 3.0相机是高分辨率且高速的解决方案，适用于从生物识别到监控的各种应用。Pixelink?USB 3.0相机具有高达14MP的分辨率、高达150fps的帧率以及适用于各种功率和高数据吞吐量的USB 3.0兼容性。直角外壳配置还具有GPIO，可启用触发以便于系统集成。这些USB 3.0相机还能与尺寸从?"到1.1"的传感器兼容，并且非常适合检查焊接和PCB以及平板显示器。

　　Pixelink USB 3.0相机通用规格

　　相机系列:PL-D

　　生产商:Pixelink?

　　曝光控制触发器:Freely Programmable

　　支架:C-Mount

　　操作系统:Software Driver:Windows 32 and 64 bit

　　功率要求:Via USB 3.0 interface

　　工作温度(°C):0 to+50

　　传感器类型:Progressive Scan CMOS

　　视频输出:USB 3.0

　　订购信息：

　　型号摄像机传感器格式分辨率像素(HxV)类型产品编码

　　(MegaPixels)

　　PL-D721MU-T 1/2"1.3 1,280 x 1,024 Monochrome Camera#89-378

　　PL-D721CU-T 1/2"1.3 1,280 x 1,024 Color Camera#89-379

　　PL-D721MU-BL 1/2"1.3 1,280 x 1,024 Monochrome Camera#89-380

　　PL-D721CU-BL 1/2"1.3 1,280 x 1,024 Color Camera#89-381

　　PL-D722MU-T 2/3"2.3 1,920 x 1,200 Monochrome Camera#89-382

　　PL-D722CU-T 2/3"2.3 1,920 x 1,200 Color Camera#89-383

　　PL-D722CU-T 2/3"2.3 1,920 x 1,200 Color Camera#89-383-RCD-05P

　　PL-D722MU-BL 2/3"2.3 1,920 x 1,200 Monochrome Camera#89-384

　　PL-D722CU-BL 2/3"2.3 1,920 x 1,200 Color Camera#89-385

　　PL-D775MU-T 1/2.5"5 2,592 x 1,944 Monochrome Camera#89-386

　　PL-D775CU-T 1/2.5"5 2,592 x 1,944 Color Camera#89-387

　　PL-D725MU-T 1"5.3 2,592 x 2,048 Monochrome Camera#89-390

　　PL-D775MU-BL 1/2.5"5 2,592 x 1,944 Monochrome Camera#89-388

　　PL-D775CU-BL 1/2.5"5 2,592 x 1,944 Color Camera#89-389

　　PL-D725CU-T 1"5.3 2,592 x 2,048 Color Camera#89-391

　　PL-D729MU 2/3"9.6 3,840 x 2,500 Monochrome Camera#89-394

　　PL-D729MU 2/3"9.6 3,840 x 2,500 Monochrome Camera#89-394-RCD-05P

　　PL-D725MU-BL 1"5.3 2,592 x 2,048 Monochrome Camera#89-392

　　PL-D725CU-BL 1"5.3 2,592 x 2,048 Color Camera#89-393

　　PL-D725CU-BL 1"5.3 2,592 x 2,048 Color Camera#89-393-RCD-05P

　　PL-D729MU 2/3"9.6 3,840 x 2,500 Monochrome Camera#89-396

　　PL-D7715CU 1/2.3"15 4,608 x 3,288 Color Camera#89-398

　　PL-D7715CU-BL 1/2.3"15 4,608 x 3,288 Color Camera#89-400

　　PL-D726MU-BL 1"6.6 2,208 x 3,000 Monochrome Camera#89-402

　　PL-D732MU-T 2/3"2.2 2,048 x 1,088 Monochrome Camera#33-338

　　PL-D732CU-T 2/3"2.2 2,048 x 1,088 Color Camera#33-339

　　PL-D732MU-BL 2/3"2.2 2,048 x 1,088 Monochrome Camera#33-340

　　PL-D732CU-BL 2/3"2.2 2,048 x 1,088 Color Camera#33-341

　　PL-D734MU-T 1"4.2 2,048 x 2,048 Monochrome Camera#33-342

　　PL-D734CU-T 1"4.2 2,048 x 2,048 Color Camera#33-343

　　PL-D734MU-BL 1"4.2 2,048 x 2,048 Monochrome Camera#33-344

　　PL-D734CU-BL 1"4.2 2,048 x 2,048 Color Camera#33-345

　　PL-D752MU-T 1/1.2"2.3 1,920 x 1,200 Monochrome Camera#33-346

　　PL-D752CU-T 1/1.2"2.3 1,920 x 1,200 Color Camera#33-347

　　PL-D752MU-BL 1/1.2"2.3 1,920 x 1,200 Monochrome Camera#33-348

　　PL-D752CU-BL 1/1.2"2.3 1,920 x 1,200 Color Camera#33-349

　　PL-D795 2/3"5.01 2,448 x 2,048 Monochrome Camera#38-005

　　PL-D795 2/3"5.01 2,448 x 2,048 Color Camera#38-006

　　PL-D795 2/3"5.01 2,448 x 2,048 Color Camera#38-006-RCD-05P

　　PL-D799 1"9 4,096 x 2,160 Monochrome Camera#38-007

　　PL-D799 1"9 4,096 x 2,160 Color Camera#38-008

　　PL-D7912 1.1"12 4,096 x 3,000 Monochrome Camera#38-009

　　PL-D7912 1.1"12 4,096 x 3,000 Color Camera#38-010

　　PL-D755MU-T 2/3"5.01 2,448 x 2,048 Monochrome Camera#11-436

　　PL-D755CU-T 2/3"5.01 2,448 x 2,048 Color Camera#11-437

　　PL-D755MU-BL 2/3"5.01 2,448 x 2,048 Monochrome Camera#11-438

　　PL-D755CU-BL 2/3"5.01 2,448 x 2,048 Color Camera#11-439

　　PL-D759MU-T 1"8.85 4,096 x 2,160 Monochrome Camera#11-440

　　PL-D759CU-T 1"8.85 4,096 x 2,160 Color Camera#11-441

　　PL-D759MU-BL 1"8.85 4,096 x 2,160 Monochrome Camera#11-442

　　PL-D759CU-BL 1"8.85 4,096 x 2,160 Color Camera#11-443

　　PL-D7512MU-T 1.1"12.29 4,096 x 3,000 Monochrome Camera#11-444

　　PL-D7512CU-T 1.1"12.29 4,096 x 3,000 Color Camera#11-445

　　PL-D7512MU-BL 1.1"12.29 4,096 x 3,000 Monochrome Camera#11-446

　　PL-D7512CU-BL 1.1"12.29 4,096 x 3,000 Color Camera#11-447

　　技术数据

　　技术信息

　　Software Specifications

　　Pixelink?API Control

　　Line Profiling:Single,Multiple,Parallel and Polyline Commands Provide Gray/Red/Green/Blue Intensity Values for Specific Lines within an Image.The Profile Data of Each Pixel on the Line Can Be Exported to Microsoft?Excel?.

　　Multiple Image File Formats:jpg,jpeg,tif,tiff,bmp,gif,pcx,tga,mpg,mpeg,avi,mov,img,rpt,txt

　　Overlay:Crosshair,Grid Mask,Image,Marker

　　Image:Mode Change,Clone,Crop,ROI,Resize,Rotate

　　Zoom Control:100-1600%and Fit to Window Options

　　Annotation:Line,Arrow,Polyline,Spline,Rectangle,Ellipse,Text

　　Image Sequence Control

　　Image Editing:Undo,Redo,Copy,Paste,Paste New,Delete,Delete All,Annotate,Image Information

　　Multiple Window Configurations

　　Export to Excel?:Images with Measurement,Calibration,Annotations,Measurement Data,Statistics,and Chart

　　Measurement Parameters:Area,Max Length,Line Length,Center x and y,Angle

　　Live Measurement and Overlay:Perform Measurements on the Live Preview Image,Using the Crosshair or Grid Masks to Center and Count.The Grid Masks include Calibration Data.

　　Dynamic User Interface

　　Manual Calibration

　　Report Generator:Create,Insert Images and OLE Objects

　　Manual Measurement Tools:3-Point Circle Functionality,npoint Circle Measurement Functionality,Parallel Line Distance Measurement,Perpendicular Distance Measurement and Object Distance Measurement,Zoom-In Window

　　Time Lapse Capture and Movie File Production with Crosshair on Live Preview

　　Calibration Marker(Scale Bar)Can Be Placed on the Live Preview Image and Burned in Automatically

　　Multiple ROI:Shapes and Copy,Paste,Crop ROI

　　Image Processing:manual brightness,contrast,gamma,background subtraction,histogram,clone,crop,ROI,resize,rotate,split,image mode change,grayscale,RGB,HSB,YUV pseudo color view

　　Auto and Semi-Auto Calibration

　　Profile:Straight line,Polyline,Parallel Line,Select and Change

　　Image Stitching

　　Z-axis Extended Focus Imaging with Displacement Compensation

　　3D Visualization to Clearly View Complex Structures

　　Auto Trace Using Automatic Edge Detection

　　Fluorescent Image Composition

　　Fast and Perfect Focus Enhancement

　　Shading Correction

　　Reflected Light Subtraction
